MGCP-1000

Special Design for Hard Gold Ore

MGCP-1000 is engineered for high-density gold ore processing, providing maximum efficiency in primary and secondary crushing, pre-screening, and material handling. It is also adaptable for silver, molybdenum, or polymetallic ores.

All units are built with abrasion-resistant materials and integrated with dust suppression, noise control, and environmental safety features. Maintenance platforms, service ladders, and safe access points ensure operator safety during continuous operation.

Main Components

• Primary Jaw Crusher – MJ200

  • Feed opening: 1400 × 1100 mm

  • Power: 200 kW

  • Heavy-duty, high-capacity primary crushing

• Secondary Impact Crusher – MPI1315

  • Rotor: 1,300 × 1,500 mm (ØxW)

  • Power: 315 kW

  • High-throughput secondary crushing

  • Optional 2, 3, or 4 BlowBars

  • MAGOTTEAUX™ wear parts

• Triple-Deck Vibrating Screen – MHS820

  • Dimensions: 2480 × 6100 mm

  • Power: 45 kW

  • Triple-shaft design for precise particle separation

• Vibrating Grizzly Feeder – MGF1260

  • Dimensions: 1300 × 5200 mm (WxL)

  • Grizzly length: 3,000 mm

  • Heavy-duty single-section feeder, adjustable grizzly gap

• Belt Conveyors – MCV15

  • Width: 1500 mm, EP125, 5-ply, heavy-duty

  • Length: up to 50 meters, impact bed and foldable options

• Magnetic Separator – MAGNET

  • Permanent magnet for ferrous separation at critical transfer points

Technical Specifications

• Capacity: 1,000 TPH

• Feed Size: 0–700 mm

• Output Sizes: 0–5 mm, 5–12 mm, 12–22 mm, 22–32 mm, 32–50 mm

• Installed Power: 350–600 kW

• Efficiency: Optimized energy use, up to 20% lower OPEX

• Wear Life: Heavy-duty wear parts with 35% longer service life

Plant Features

• Jaw & impact crushers with customizable profiles and MAGOTTEAUX™ wear parts

• 2–4 deck vibrating screens with adjustable grizzly and wash nozzles

• Heavy-duty belt conveyors, EP400/galvanized, hydraulic adjustment, radar monitoring

• Permanent magnets and 1-way or 2-way detectors

• Portable trailer-mounted or tracked conveyors (generator included)

Optional Equipment & Features

• Heavy-duty structure for continuous operation

• Triple-deck screens and high-capacity conveyors for accurate particle sizing

• Dust and noise suppression systems

• Full environmental safety infrastructure

• Automation-ready for real-time process monitoring

Applications

• Hard rock gold mining: primary and secondary crushing, pre-screening

• Pre-flotation beneficiation and ore preparation

• Mining sites requiring ore sizing, crushing, and material transfer

• Adaptable for silver, molybdenum, or polymetallic ores
