Special Design for Hard and Abrasive Quartz

MINEVATE quartz crushing & screening plants are specifically engineered for hard and abrasive quartz ores. With multi-stage crushing and precise screening technology, these plants produce high-purity quartz sand and aggregates. The design ensures energy efficiency, long-lasting wear parts, and minimal maintenance requirements.

Main Components of Quartz Crushing & Screening Plants

• Feeding Unit: 30–60 m³ hopper, wear-resistant liners, vibrating feeder

• Primary Crusher: Jaw Crusher, 200–400 tph, reinforced jaw plates

• Secondary Crusher: Cone Crusher with automated adjustment, quartz-optimized design

• Tertiary Crusher (Optional): VSI impact crusher, ideal for 0–5 mm quartz sand

• Screening Unit: 2–3 deck vibrating screen, stainless steel meshes

• Conveyors: 500–1000 mm, dust-proof, abrasion-resistant belts

Technical Specifications

• Capacity: 200–400 tph

• Feed Size: 0–600 mm

• Output Sizes: 0–5 mm, 5–12 mm, 12–22 mm, 22–32 mm

• Installed Power: 300–500 kW

• Efficiency: Up to 15% energy saving

• Wear Life: Special alloy parts with 30% longer service life

Advantages of MINEVATE Quartz Plants

• Optimized for hard and abrasive quartz

• Cubic product shape with low fines ratio

• High capacity with low maintenance

• Dust control and eco-friendly operation

• Global service and spare parts support

Applications

• Glass Industry: Container, flat, and automotive glass

• Ceramics & Porcelain: Strength and brightness enhancer

• Foundry Industry: Heat-resistant quartz casting sand

• Construction: Concrete, asphalt, and building aggregates

• Metallurgy & Refractories: Steel production, refractory bricks

• Chemical Industry: Silica-based products, silicone, silica gel

• Energy & Electronics: Solar panels, semiconductors

Optional Features & Services

• Global installation and on-site training

• Remote monitoring and automation package

• Dust suppression and water spraying system

• Extra wear-resistant liners for extended life

• Extended warranty packages (12–24 months)

• Energy-saving motors and variable frequency drives (VFD)
